MIR Spirodoc® Touchscreen Spirometer
The Spirodoc® Spiro is a handheld, portable diagnostic spirometer with touchscreen display. The device can be configured to operate with advanced parameters for full spirometry, reduced parameters set for simple screening and a simple mode for patient home use.
The device features a high resolution touch screen display. Powered by its long life rechargeable battery, the Spirodoc® is capable of storing up to 10,000 tests on its built in memory. When patients are sent away with a Spirodoc®, the device can be set to patient mode which features an “eDiary”. This allows patients to answer pre-configured questions about their symptoms that correlates with any tests recorded for that day.
The Spirodoc® can also connect wirelessly to a PC via Bluetooth® (or directly via USB) allowing for real-time spirometry testing, and downloading of test results stored on the device using the free MIR WinspiroPRO® PC Software.
A full range of selectable parameters
The Spirodoc® Spiro measures an array of selectable parameters and gives a PRE and POST bronchodilator comparison. Results are previewed on the display following a test, with a flow/volume graph in addition to the patient’s actual spirometry readings for immediate assessment together with interpretation.
Spirometry Parameters
FVC, FEV1, FEV1/FVC, FEV1/VC, PEF, FEF25, FEF50, FEF75, FEF25–75, Lung Age, Extrap. Volume, FET, FEV3, FEV3/FVC, FEV6, FEV1/FEV6, FIVC, FIV1, FIV1/FIVC, PIF, VC, IVC, IC, ERV, Rf, VE, VT, tI, tE, VT/tI, tE/tTOT, MVV measured, MVV calculated.
6 Minute Walk Test – Specific parameters (Optional)
O2–Gap, Estimated Distance, Walked Distance, Predicted Distance (Min, Standard), T∆2% (SpO2≥2%), T∆4% (∆SpO2≥4%), Time (Rest, Walking, Recovery), Desaturation Area/Distance Optional dataentry: BorgDyspnea(Baseline, End,Change), BorgFatigue (Ba- seline, End, Change), Arterial blood pressure (Systolic, Diastolic), Oxygen administered.
3D accelerometer with motion analysis
Spirodoc® is the first “3D Oximeter®” to incorporate a three axis movement sensor to correlate the saturation level (%SpO2) to the physical activity.
Spirodoc® – Smart Pulse Oximeter with on-screen results
Spot Oximetry Test
The oximeter is a true “life-saver” because it can measure the severity of the illness in just a few seconds, allowing a more accurate and timely diagnosis to be performed in the doctor office or at home.
Spirodoc istantly provides simple and clear SpO2 and HR measurements with a view of the plethysmographic curve.
6 Minute Walking Test (6MWT)
During the walking test, the patient walks as fast as possible in a 30 meter long hallway for 6 minutes with the administration of oxygen, if necessary.
Thanks to the portability and advanced features of Spirodoc it is possible to test patients easily.By doing this, it’s possible to correlate the SpO2 saturation level to physical activity, which is extremely useful for diagnosing effort-induced bronchospasm, for COPD assessment and treatment. Spirodoc is provided with belt.
Sleep Oximetry Test
Spirodoc carries out a sleep desaturation analysis and memorizes events as well as body position, allowing a fast and reliable diagnosis.
OSAS (Obstruction Sleep Apnea Syndrome) has become something of an epidemic.
It is safe to say that wherever we turn in the world OSAS is there.
Spirodoc carries out a sleep desaturation analysis and memorizes events as well as body position, allowing a fast and reliable diagnosis.
24h Holter Test
The 24 hour Holter Test provides a comprehensive analysis of the entire recording period and determines the average SpO2 values and pulse rate. This analysis gives an overall evaluation of the cardio-respiratory conditions throughout the day.
Virtually all advanced oxygen devices are now built with a new technology that has a valve for the “on request” administration of oxygen… which means that oxygen can be given to the patient if it needs it.
Spirodoc automatically measures and records desaturation events while standing or walking or sleeping and translates them into the amount of oxygen required by the patient.
In addition, Spirodoc allows fast on-screen symptoms entry with settable questions and automatic answer recording (eDiary).
A detailed analysis of the most significant periods can therefore be performed: for example at rest or while exercising.
Thanks to the built-in accelerometer, SPIRODOC can differentiate between light physical activity, moderate/heavy and sleep, and then determine the exact amount of oxygen that the patient needs in the various phases.
Key Features
- Handheld spirometer with touchscreen
Navigate easily through the icon-based menus on a clear, high resolution screen - Three functional modes
Choose between full spirometry mode, basic screening mode or patient mode for home testing - Patient’s home-care symptoms eDiary
With patient mode enabled, users can monitor themselves and record their symptoms - Large memory storage
Store up to 10,000 tests - Bluetooth® and USB connectivity to PC
Download results stored on the device and conduct real-time spirometry using WinspiroPRO® PC software - Spiro + Oximetry version available
